Highlights

Containers package application code and dependencies into a single, isolated, and immutable environment.
Pods are the smallest deployable units in Kubernetes, acting as a "house" that hosts one or multiple co-located containers.
Nodes are the physical or virtual machines running your workloads, divided into master nodes (control plane) and worker nodes (application execution).
The master node manages the cluster's state using core components like the API Server, Scheduler, Controller Manager, and etcd.
Worker nodes run the actual applications using components like Kubelet, Kube-proxy, and a Container Runtime.

Kubernetes is an open-source container orchestration tool created by Google. It eases the work of managing containerized applications at scale by automating tasks such as deployment and scaling. Mastering the right DevOps terminology is essential for anyone entering this field.

This blog explores the meaning of four fundamental Kubernetes terms that you'll come across many times when working with Kubernetes: Containers, Pods, Nodes, and Clusters. This guide serves as your essential Kubernetes glossary, clearly covering the pods nodes cluster meaning to help you build a strong foundation in Kubernetes basics.

Containers

Let's take a step back and answer the question: What does the term “containerized” mean?

A containerized application is an application that has been packaged as one or more containers. You can think of a container as a box that includes everything an application needs to run. This includes the application code, libraries, and dependencies.

For example, say we have packaged a Node.js web application as a container. To run the application, the container would need the following:

Node.js runtime
Application code
And other libraries and dependencies.

The task of packaging an application into an image that can be run as a container is mostly accomplished using Docker.

An image is a static file that serves as a blueprint for creating a container. A container is a running instance of an image.

When you create a container from an image, the application included in the image runs inside the container. The container provides an isolated environment for the application to run in. This means you can be confident that the application will run the same way regardless of the environment it's deployed in.

To understand why we need containers, let’s consider a simple example. Imagine that you have a web application written in Python. Let’s say you want to share the application with someone else. Or you want to deploy the application in a test or production environment.

To run your application, the other person or environment would need to have a specific version of Python installed. Also, they would need to have installed any dependencies your application requires. This can be difficult to manage, especially if you are dealing with multiple people or environments.

Try the Docker Familiarize Environment Lab for free

This is where having Kubernetes concepts explained clearly shows why containers come to your rescue. With containers, you can package your entire application and its dependencies into a container image. The container image can then be run on any machine with a container runtime (a piece of software) installed. When a container image is run, the container runtime starts the container & executes the application code. This means that the other person or environment can run your application without worrying about installing the specific version of Python or other dependencies.

Containers make it easy to deploy applications on different platforms & environments. The applications run consistently and reliably, no matter what system they run on.

Stateless & Immutable

In Kubernetes, containers are stateless & immutable.

Stateless: A stateless container is a container that does not store any data. The container does not maintain any information about its previous state or any data it has processed. This makes it easier for Kubernetes to create and destroy containers at any time. No new state could be lost when a container is destroyed. And when a container is created, no old state needs to be recovered.
Immutable: In Kubernetes, a container is considered immutable. This means that the contents of the container, such as the application code, libraries, and system files, can’t be modified once the container has been built. The only way to update the contents is to create a new container and deploy it in place of the old one. This also makes some things easier for Kubernetes. For example, scaling up when there is high demand for the application. To scale up, Kubernetes just launches multiple instances of the same container – basically clones. You want all clones to work exactly the same way. Immutability ensures they are all identical at all times.

In Kubernetes, we never interact with containers directly. Instead, we work with Pods. Kubernetes uses Pods to manage and schedule containers.

So, what are Pods?

Pods

In Kubernetes terminology, Pods are a core building block. They host and manage the containers that run our applications. Think of them as the house where containers live in.

A Pod can host a single container or multiple containers.

All the containers within a Pod are co-located, meaning they run on the same node (server). They are also co-scheduled, meaning they are scheduled to run on the same node simultaneously. This arrangement is super useful when we have applications composed of multiple containers that need to communicate with each other. Or when we want to share resources among the containers in the Pod.

For example, imagine you have a web application consisting of two containers. A frontend container that serves the user interface and a backend container that handles database queries. Without using pods, these two containers could be deployed on separate nodes. And they would need to communicate over the network using their own IP addresses.

However, when we deploy these two containers in the same pod, they can communicate without using an external network. Basically, they're super close to one another and can communicate much faster. Pods also make it easier to manage the application as a single unit. Additionally, both containers can access the same storage resources. This makes it easier for them to share and work with the same data.

Features

All Pods share one important characteristic: they are impermanent in nature. This means that they can be created and destroyed as needed. Even when nodes fail, our applications continue to run and remain available. For example, if a worker node running four pods fails, Kubernetes will reschedule the lost pods and containers to run on healthy nodes.

Now that we understand what Pods are, we need to understand what nodes are because Pods run on nodes.

Nodes

Nodes are the physical or virtual machines that are used to run pods. In Kubernetes, there are two distinct types of nodes: master and worker nodes.

Master Node

The master nodes host the control plane, which is responsible for managing the state of a Kubernetes cluster. All of the interconnected master and worker nodes make up a Kubernetes cluster. And this cluster is the platform we use to deploy and host containers.

Master nodes are basically the "brains" behind Kubernetes. But why do we need multiple master nodes? We could have just one, and our cluster would work just fine. But if that node fails, the control plane becomes unavailable. So having multiple master nodes helps with reliability. If one master node fails, the others can still do their job.

The control plane monitors containers and coordinates actions across the cluster. Users can communicate with a Kubernetes cluster by sending requests to the control plane.

Worker Node

Worker nodes are responsible for running containers. We never directly interact with the worker nodes. We send instructions to the control plane. The control plane then delegates the task of creating and maintaining containers to the worker nodes.

Cluster

A Kubernetes cluster is a group of nodes used to run containerized applications. It is composed of master node components and worker node components.

Master Node Components

A master node runs the following components:

API Server: The API server provides the main entry point for interacting with the cluster. In simple terms, it is a web server that listens for incoming HTTP requests. It exposes the Kubernetes API that external clients use to communicate with the cluster. For example, an external client could use the Kubernetes API to get a list of all the running Pods.
Scheduler: The scheduler is responsible for finding the nodes for Pods to run in. First, it filters the nodes that are eligible to run the Pod. Once it has a list of eligible nodes, it uses a scoring function. The scoring function determines the best node to run the Pod. The node with the highest score is selected as the target for the Pod.
Controller Manager: One of the main functions of the Kubernetes controller manager is to maintain the desired state of the cluster. Let’s say a user wants 3 replicas (copies) of an application. The controller manager will then ensure that 3 copies of the application are running at all times. It does this by periodically checking if the current state matches the desired state. If it's not a match, it takes corrective actions.
etcd: etcd is a key-value data store that stores the state of a Kubernetes cluster. Clients can always read the latest data from the store.

Worker Node Components

A worker node has the following components:

Kubelet: Kubelet is the primary interface between the node and the Kubernetes control plane. It communicates with the API server to receive information about the pods that are assigned to the node. Then it takes action to ensure that pods are running and healthy. This includes tasks such as starting and stopping containers, managing their resource allocation, and monitoring their health.
Kube-proxy: Kube-proxy maintains network rules on nodes. These rules determine how traffic is allowed to flow to and from the Pods. For example, a rule might specify that traffic from a particular IP address is allowed to reach a particular Pod. These rules ensure that Pods can communicate with each other and with external networks as needed.
Container runtime: Container runtime is the software responsible for actually running the containers. It provides the infrastructure and functionality required to create and manage containers. Kubernetes supports container runtimes such as containerd and CRI-O.

Pods, containers, nodes, and clusters form the foundation of Kubernetes. A strong understanding of these terms and concepts is key to understanding how Kubernetes works.

Why Learn Kubernetes

Kubernetes has witnessed the fastest growth in job searches, with a staggering increase of over 173% in just one year! According to recent surveys conducted by Indeed, the demand for Kubernetes skills is skyrocketing.

To boost your professional credibility, you can earn certifications like CKAD, CKA, and CKS, which will attest to your expertise in Kubernetes. The courses below will help you prepare for these three in-demand certifications.

Don’t know where to start your certification journey, check out the blog CKAD vs. CKA vs. CKS.

To learn more about the three certifications, check out our CKA, CKAD, CKS - Frequently Asked Questions blog.

Conclusion

In the container orchestration space, Kubernetes is the clear winner. It was released in 2014. Since then, its adoption has been on the rise. It is now widely used by small and large organizations across the world.

To test your expertise in Kubernetes, try our FREE Kubernetes challenges.

FAQs

Q1: Why are containers considered immutable in standard Kubernetes terms?

In Kubernetes, a container is considered immutable because its contents such as application code, libraries, and system files cannot be modified once built. To update an application, you must create an entirely new container and deploy it in place of the old one.

Q2: What is the primary difference between a Pod and a Container?

A container is the packaged, isolated environment running your application and its dependencies. A Pod is the smallest deployable unit in Kubernetes that hosts and manages one or more co-located containers, acting as the "house" they live in.

Q3: What role does the master node play in a cluster?

The master node hosts the control plane, acting as the "brain" of the Kubernetes cluster. It monitors containers, maintains the desired state of the cluster, and coordinates actions across worker nodes using core components like the API Server, Scheduler, and etcd.

Q4: How do multiple containers inside a single Pod communicate?

Containers within the same Pod share the same local network interface and storage resources. Because they are co-located, they can communicate with each other much faster without needing an external network.

Q5: What is the purpose of Kubelet on a worker node?

Kubelet is the primary agent running on a worker node. It communicates with the API server on the master node to receive pod assignments, and takes action to ensure those assigned containers are running, healthy, and properly allocated resources.
