Building an AI Agent for Automated API Security Testing Using Python

Scanners catch misconfigurations. They miss the authorization flaws that cause real breaches. Here is an agent that does not.

The 2026 edition of Akamai's API Security Impact Survey, fourth in the series, reported that 87 percent of organizations suffered an API security incident, at an average cost close to 700,000 dollars. The gap that produces those numbers is specific and measurable: the top risk on the OWASP API Security Top 10 is broken object level authorization, and it is nearly invisible to the automated scanners most teams rely on. Salt Security's research adds the detail that explains why, reporting that the overwhelming majority of API attacks arrive through authenticated sessions. The attacker is not bypassing your login. They are logging in legitimately and then reading somebody else's records.

A scanner cannot catch that, because there is no malformed payload and no error signature to match. A request for order 1043 looks exactly like a request for order 1044. Deciding whether the second one is a vulnerability requires knowing that the caller owns the first and not the second, which is business context rather than pattern matching. That is precisely the gap an AI agent for API security testing fills, and this tutorial builds one in Python from an OpenAPI specification to a SARIF report your pipeline can gate on.

What an AI agent for API security testing is

An AI agent for API security testing is a language model with HTTP tools that reads an API specification, reasons about which endpoints expose object ownership or privileged functions, generates and executes targeted probes against an authorized environment, and reports each confirmed weakness with the exact request and response pair that proves it.

The distinction from a scanner is where the test cases come from. A scanner carries a fixed library of checks and applies them to whatever it finds. An agent derives its checks from your specification, which is why it can reason that GET /accounts/{accountId}/statements implies an ownership boundary worth testing while GET /health does not.

Rules of engagement, before any code

This is a tool that sends adversarial traffic at a running system, so scope discipline is part of the build rather than a disclaimer at the end.

Test only systems you own or have written authorization to test, since unauthorized testing is unlawful in most jurisdictions regardless of intent. Point the agent at staging or a dedicated test environment rather than production, because authorization probes create records, trigger alerts, and consume quota. Use purpose made test accounts with seeded data, never real customer identities. Confirm findings to the minimum degree that proves the flaw, which means reading one unauthorized record rather than enumerating the table. Coordinate with whoever watches your alerts, because an effective run looks exactly like an attack in your logs, and that is the point.

Encode those rules in the tool layer rather than in a prompt, because a prompt is advice and code is enforcement.

Architecture

Five stages, each feeding the next.

The loader parses the OpenAPI specification into a normalized endpoint inventory with paths, methods, parameters, and declared authentication. The planner asks the model which endpoints carry object ownership or privileged function semantics, and what a violation would look like for each. The executor runs probes through a guarded HTTP client that enforces scope, method, and rate limits. The verifier replays anything that looks like a finding using a second identity to eliminate false positives. The reporter deduplicates, scores, and emits SARIF plus a human readable summary.

Step 1: Turn the specification into an inventory

Everything starts with the spec, because it encodes the ownership relationships the agent needs to reason about.

from dataclasses import dataclass, field
import yaml

@dataclass
class Endpoint:
    path: str
    method: str
    operation_id: str
    path_params: list = field(default_factory=list)
    query_params: list = field(default_factory=list)
    requires_auth: bool = False
    summary: str = ""

def load_spec(path: str) -> list[Endpoint]:
    """Normalize an OpenAPI 3.x document into a flat endpoint inventory."""
    spec = yaml.safe_load(open(path))
    global_security = bool(spec.get("security"))
    endpoints = []

    for route, operations in spec.get("paths", {}).items():
        shared = operations.get("parameters", [])
        for method, op in operations.items():
            if method not in {"get", "post", "put", "patch", "delete"}:
                continue
            params = shared + op.get("parameters", [])
            endpoints.append(Endpoint(
                path=route,
                method=method.upper(),
                operation_id=op.get("operationId", f"{method}_{route}"),
                path_params=[p["name"] for p in params if p.get("in") == "path"],
                query_params=[p["name"] for p in params if p.get("in") == "query"],
                requires_auth=bool(op.get("security", global_security)),
                summary=op.get("summary", ""),
            ))
    return endpoints

The path_params list is the important output. An endpoint with a path parameter that names an object, such as {accountId} or {invoiceId}, is a candidate for the authorization tests that follow. An endpoint with no object reference usually is not.

Step 2: Build the guarded HTTP client

This is the safety boundary. The agent never gets a raw HTTP library.

import time
import httpx
from urllib.parse import urlparse

class ScopeViolation(Exception):
    """Raised when the agent tries to act outside authorized scope."""

class GuardedClient:
    BLOCKED_METHODS = {"DELETE"}          # destructive by default
    MIN_INTERVAL = 0.2                    # 5 requests per second ceiling

    def __init__(self, allowed_hosts: set[str], identities: dict[str, dict]):
        self.allowed_hosts = allowed_hosts
        self.identities = identities      # {"tenant_a": {...headers}, ...}
        self._last_call = 0.0
        self._log: list[dict] = []

    def request(self, method: str, url: str, identity: str,
                json_body: dict | None = None) -> dict:
        host = urlparse(url).netloc
        if host not in self.allowed_hosts:
            raise ScopeViolation(f"{host} is not in the authorized scope")
        if method.upper() in self.BLOCKED_METHODS:
            raise ScopeViolation(f"{method} is blocked for this run")
        if identity not in self.identities:
            raise ScopeViolation(f"unknown test identity {identity}")

        wait = self.MIN_INTERVAL - (time.monotonic() - self._last_call)
        if wait > 0:
            time.sleep(wait)

        response = httpx.request(
            method, url, headers=self.identities[identity],
            json=json_body, timeout=15.0, follow_redirects=False,
        )
        self._last_call = time.monotonic()

        record = {
            "method": method, "url": url, "identity": identity,
            "status": response.status_code,
            "body": response.text[:2000],      # truncated evidence
            "elapsed_ms": int(response.elapsed.total_seconds() * 1000),
        }
        self._log.append(record)               # every call is evidence
        return record

Four properties make this safe enough to run in a shared environment. The host allowlist means a hallucinated URL raises an exception rather than reaching a third party. Destructive methods are blocked by default and enabled only deliberately. Rate limiting keeps a testing run from becoming a denial of service. Every request and response is logged, which serves both as evidence for findings and as an audit trail for whoever asks what the tool did.

Step 3: Teach it the test scanners cannot run

Here is the core of the tutorial. Broken object level authorization is detected by comparing what two identities can see, and that comparison is mechanical once you have the right two requests.

@dataclass
class Finding:
    rule_id: str
    severity: str
    endpoint: str
    title: str
    evidence: dict
    remediation: str

def test_bola(client: GuardedClient, base_url: str, endpoint: Endpoint,
              owned_ids: dict[str, str]) -> Finding | None:
    """
    Ownership probe. Identity A holds a resource. Identity B asks for it.
    A correct API answers 403 or 404. A 200 with matching content is BOLA.
    """
    if not endpoint.path_params or endpoint.method != "GET":
        return None

    param = endpoint.path_params[0]
    victim_id = owned_ids.get(param)          # object owned by tenant_a
    if not victim_id:
        return None

    url = base_url + endpoint.path.replace("{" + param + "}", victim_id)

    baseline = client.request("GET", url, identity="tenant_a")
    if baseline["status"] != 200:
        return None                            # seed data wrong, skip quietly

    probe = client.request("GET", url, identity="tenant_b")
    if probe["status"] != 200:
        return None                            # correctly denied

    if probe["body"][:200] != baseline["body"][:200]:
        return None                            # different content, not a leak

    return Finding(
        rule_id="API1-BOLA",
        severity="high",
        endpoint=f"{endpoint.method} {endpoint.path}",
        title="Cross tenant object access through path parameter",
        evidence={"authorized": baseline, "unauthorized": probe},
        remediation=(
            "Check object ownership server side on every request that accepts "
            "an object identifier. Do not rely on identifier unpredictability."
        ),
    )

Read what that function proves. It establishes that tenant A legitimately sees a record, then shows tenant B receiving byte identical content for the same object. That is not a heuristic, it is a demonstration, and it is why the finding ships with both halves of the comparison attached.

The same shape covers broken function level authorization. Swap the second identity for a standard user and target an administrative operation, and a 200 response where you expected a 403 is your finding.

Want a cluster and API to break safely?

Security testing is a skill you build by attacking things you are allowed to attack. The DevSecOps learning path on KodeKloud covers pipeline security and testing practice, the Python courses build the scripting foundation this agent depends on, and the KodeKloud playgrounds give you disposable environments where you can host a deliberately vulnerable API and run your agent against it without touching anything that matters.

Step 4: Let the model plan, keep the tools deterministic

The model's job is judgment about which endpoints matter and what a violation looks like. The execution stays in code you wrote.

import json

PLANNER_PROMPT = """You are an API security analyst. Given this endpoint
inventory, identify endpoints that carry authorization risk.

For each, return an object with:
  operation_id, risk ("BOLA"|"BFLA"|"BOPLA"|"none"),
  reason (one sentence), ownership_param (path param naming an object, or null)

Prioritize endpoints whose path parameters reference user owned objects and
endpoints whose summary implies administrative or privileged behavior.
Return only a JSON array.

Inventory:
{inventory}"""

def plan_tests(endpoints: list[Endpoint], llm) -> list[dict]:
    inventory = [
        {"operation_id": e.operation_id, "method": e.method, "path": e.path,
         "path_params": e.path_params, "summary": e.summary}
        for e in endpoints
    ]
    raw = llm(PLANNER_PROMPT.format(inventory=json.dumps(inventory, indent=2)))
    text = raw.strip()
    if text.startswith("`"):                  # strip a markdown fence if present
        text = text.strip("`").removeprefix("json").strip()
    plan = json.loads(text)
    return [item for item in plan if item.get("risk") != "none"]

Splitting responsibilities this way matters more than it might look. The model never emits a URL that gets called blindly, never chooses an HTTP method, and never decides whether something is a finding. It reads names and summaries and says where to look, which is the part it is genuinely good at, while every consequential action runs through the guarded client and every verdict comes from a deterministic comparison.

Step 5: Report evidence, not opinions

A finding without a reproduction is a ticket that gets closed as "cannot reproduce." Emit SARIF so findings land in GitHub code scanning alongside your other results.

def to_sarif(findings: list[Finding]) -> dict:
    return {
        "$schema": "https://json.schemastore.org/sarif-2.1.0.json",
        "version": "2.1.0",
        "runs": [{
            "tool": {"driver": {
                "name": "api-security-agent",
                "informationUri": "https://example.internal/api-security-agent",
                "rules": [{
                    "id": f.rule_id,
                    "shortDescription": {"text": f.title},
                    "help": {"text": f.remediation},
                } for f in {f.rule_id: f for f in findings}.values()],
            }},
            "results": [{
                "ruleId": f.rule_id,
                "level": {"high": "error", "medium": "warning"}.get(f.severity, "note"),
                "message": {"text": (
                    f"{f.title} on {f.endpoint}. "
                    f"Authorized request returned {f.evidence['authorized']['status']}, "
                    f"unauthorized identity returned {f.evidence['unauthorized']['status']} "
                    f"with matching content."
                )},
                "locations": [{"physicalLocation": {
                    "artifactLocation": {"uri": "openapi.yaml"},
                }}],
            } for f in findings],
        }],
    }

Wire it into the pipeline so results gate the merge rather than filling a report nobody opens.

name: API security agent
on:
  pull_request:
    paths: ["openapi.yaml", "src/api/**"]

jobs:
  agent-scan:
    runs-on: ubuntu-latest
    permissions:
      security-events: write        # required to upload SARIF
      contents: read
    steps:
      - uses: actions/checkout@v4
      - name: Run the agent against staging
        env:
          TARGET_HOST: staging-api.internal
          TENANT_A_TOKEN: ${{ secrets.TENANT_A_TOKEN }}
          TENANT_B_TOKEN: ${{ secrets.TENANT_B_TOKEN }}
        run: python -m agent.run --spec openapi.yaml --out results.sarif
      - uses: github/codeql-action/upload-sarif@v3
        with:
          sarif_file: results.sarif

Step 6: Prove the agent actually works

Every security tool claims coverage. Measure yours before you trust it, using an API with known planted flaws.

Deliberately vulnerable applications exist for exactly this purpose, and OWASP maintains several, including crAPI and VAmPI, both of which ship documented authorization flaws. Run your agent against one and count what it catches. A detection rate below your expectation usually means the planner is missing endpoints rather than that the probe logic is wrong, which points you at prompt and inventory improvements rather than a rewrite.

Then build the piece that pays off over time. Every confirmed finding becomes a permanent regression test.

# corpus/regressions.yaml grows one entry per confirmed finding
# - rule_id: API1-BOLA
#   endpoint: "GET /accounts/{accountId}/statements"
#   probe_identity: tenant_b
#   expect_status: [403, 404]

def run_regressions(client: GuardedClient, base_url: str, corpus: list[dict]):
    """Fast deterministic replay. No model calls, runs on every commit."""
    failures = []
    for case in corpus:
        url = base_url + case["endpoint"].split(" ", 1)[1].format(**case["params"])
        result = client.request("GET", url, identity=case["probe_identity"])
        if result["status"] not in case["expect_status"]:
            failures.append({"case": case, "got": result["status"]})
    return failures

That corpus is the quiet win of the whole design. Agent runs are exploratory, cost tokens, and take minutes. Regression runs are deterministic, free, and take seconds, so they belong on every commit while the full agent run belongs on a schedule or on specification changes.

What the agent covers, and what it does not

Be honest about the fit column when you present results. An agent that claims full coverage of the Top 10 loses credibility with the first security engineer who reads the output carefully.

Where to start

1. Confirm you have written authorization to test the target, and pick a staging environment rather than production.
2. Export or generate the OpenAPI specification for one service, since inventory quality caps everything downstream.
3. Seed two test tenants with realistic data and record which object identifiers each one legitimately owns.
4. Build the guarded client first, with the host allowlist and rate limit, and verify a scope violation raises before you add any model calls.
5. Implement the ownership probe alone, run it against a deliberately vulnerable API, and confirm it catches a known planted flaw.
6. Add the planner once probes work, because a smart planner in front of broken probes produces confident nonsense.
7. Emit SARIF, upload it in CI, and convert every confirmed finding into a regression case the same day.

Conclusion

The reason authorization flaws dominate API breach reports is not that they are hard to understand. They are hard to test at scale, because catching one means knowing which user should own which record, and that knowledge lives in your domain model rather than in any scanner's rule database. Reading the specification, inferring those relationships, and designing the probe is exactly the work a language model does well, while the parts that must never be improvised, scope enforcement, request execution, and the verdict itself, stay in deterministic code.

Build the guarded client this week and write one ownership probe against a staging service you own. If it comes back clean, you have a regression test worth keeping. If it does not, you have found the class of flaw that costs organizations an average near 700,000 dollars per incident, and you found it before somebody else did.
