What Is the Difference between Docker, LXC, and LXD Containers?

Difference between Docker, LXC, and LXD Containers

Imagine you're a developer, writing a cool app for Linux servers. But some people run Ubuntu 20.04 on their servers. Others run 22.04. Others run an entirely different operating system such as Red Hat Enterprise Linux. So how do you make sure your app runs well on each operating system? Normally, developers make multiple versions of their app. One version that runs on older Ubuntu, one that runs on the newer Ubuntu, one that works with Red Hat Enterprise Linux, and so on. There need to be small adaptations to ensure the app is compatible with each operating system. This can be tedious.

Docker - a Container for a Single Application

But then Docker came along and simplified this process for developers. Now, they don't have to create variations of their app that can work on each operating system. They create a single variant, and with the help of Docker, this one version can run on pretty much any Linux operating system.

If you've never used it, we have a pretty awesome course: Docker for the absolute beginner. And this goes well with Kubernetes for the absolute beginner. Kubernetes and Docker are so incredibly popular these days, it's impossible to not get a well-paid job if you learn both of these technologies.

An application can depend on other programs, other files, system libraries, and so on. These are called dependencies. Without a container solution like Docker, developers need to look at what programs and system libraries they have available on each operating system. And then they need to make sure that their app works with those programs and libraries. Here's an example. Imagine the app needs "some_library, version 1.3". Ubuntu 22.04 has that version. But Ubuntu 20.04 has "some_library 0.9". Oops, that version is too old. Now the developer has to adapt his app for Ubuntu 20.04, so that it can work with this old library. But with Docker, they can go a different route.

They take their app and drop it inside a container. Then they take all dependencies, every extra program, library, or file that their app requires. They package these nicely, and also drop it inside that container. In our imaginary scenario, they can simply pick up "some_library 1.3" and drop it in there. Now this container includes everything that the application needs to be able to run. So it doesn't need to rely on what the operating system provides, anymore.

With the perfect container created, with all ingredients inside, the developer's job is done! Now they can ship that app to the whole world. It will work on Ubuntu, openSUSE, Red Hat Enterprise Linux, almost any Linux operating system, without requiring any changes.

So we can conclude that Docker is basically a very small box where we can drop an application and all of its dependencies. Otherwise said, it contains the environment that it needs to be able to run.

Also, a Docker container isolates this application from the rest of the system. It's very important to note that Docker is designed to isolate a single application inside a container.

Ok, so we have a pretty cool solution to develop applications that can be shipped to almost any Linux server configuration. What's the deal with LXC then?

LXC - a Container for Operating Systems

Let's think about an operating system. What are its components? First of all, it has a bootloader. This helps the computer find and load the operating system into memory. It also has a kernel that can initialize and control the computer's hardware. And it has many applications that let you do useful work on that computer. These components, and others, make up the operating system's environment. In simple terms, it has stuff that helps three different entities:

  1. It helps the computer boot up and use its hardware properly.
  2. It helps programs do their work by providing the required libraries, or whatever is needed.
  3. It helps human beings use that computer and do their work.

Some operating systems skip the third part, if human interaction is not needed. For example, this can be the case for automated electronic systems.

In our LXC discussion, the second part is the most important. The operating system provides the environment that programs need to do their work. For example, programs need the kernel to be able to use computer memory. They can't reserve system memory if the kernel doesn't help them do that. So, once again, we can say that the programs can have some dependencies. Notice how we mentioned two key words: environment and dependencies. We used the same words when we discussed Docker.

Now back to Docker. Its containers do not encapsulate an entire operating system. It doesn't need a kernel, or a bootloader, or any other complex stuff. It just needs a very tiny collection of files. Maybe a few programs and libraries, so that the app inside can do its work. Docker includes a very minimal environment. This makes Docker containers small, easy to move around, and fast to start up.

But what if we need an entire operating system in a container? The first thing that may come to mind is a virtual machine. But virtual machines are rather hard to create. First we need to assign virtual resources to that virtual machine. We need to reserve a little bit of memory, a little bit of disk space, some CPU cores. Then we need to download an operating system. Then we need to install it in that virtual machine.

It may be easy to create a virtual machine on a personal computer, right in front of you. But it's much harder to do that on a remote server, somewhere on the Internet. And it becomes even harder, considering you have to do this through commands. Furthermore, most servers we can rent online are actually virtual these days. The compute instances on the cloud are virtual machines. A VPS, virtual private server, is also, obviously, virtual. So creating a virtual machine inside a virtual machine is kind of tricky. Most cloud service providers don't even allow you to do that. Then what can we do?

Well, LXC, short for Linux Container saves the day. It makes it very easy to run containers that have an entire operating system inside. Now, if we recap, we can see the differences between Docker and LXC:

  • Docker is designed to isolate ONE application in ONE container. So it allows you to run multiple isolated applications on a server.
  • LXC is designed to isolate ONE operating system in ONE container. So it allows you to run multiple isolated operating systems on a server. In plain words, it's almost like LXC lets you run many small, imaginary computers on that server. And each imaginary small computer has its own, separate operating system.

This sounds like a pretty cool idea. But you may ask yourself: "Why would I want other operating systems running on top of my main operating system?" Well, here's an example. At KodeKloud, we have courses for students that want to learn more about Linux, servers, system administration. And we firmly believe that the easiest way to learn is through practice. So we let our students experiment with commands, directly in their browser. They basically get easy access to an environment that looks and feels like a Linux operating system. This way, they can quickly test out what they've learned, without even needing to configure their own virtual machine. One click, instant access to a test environment!

Imagine how easy it would be to do this with LXC. On a single server, we could launch a bunch of Linux Containers. You click that you want to try out commands on Ubuntu 22.04 and boom! We quickly launch a container with Ubuntu 22.04 inside. Another user comes along. We launch another, separate Ubuntu 22.04 container. And now, both users can do their work in their own isolated boxes, without affecting each other. When you click that you've finished testing commands, we can delete your LXC container.

So with Docker you can run services that rely on one application. And with LXC you can run services that rely on one operating system.

LXD Brings Super Powers to LXC

So what's the deal with LXD?

LXD still uses LXC behind the scenes. But it greatly extends LXC's functionality. It both improves LXC's existing functions, and also adds new capabilities on top of it. Here are some examples of what it brings to the table:

  • LXD improves isolation between LXC containers and the rest of the system. It makes LXC containers a bit more secure, trying to ensure a rogue container doesn't affect the rest of the system.
  • LXD allows you to live migrate containers from one server to another server. That is, you can transfer the entire container from one place to another place, while it's still running. Once the transfer is complete, it should continue running exactly from where it left off. For example, imagine a video is rendering slowly inside that container. It got all the way to 30%. But it takes too long. So you decide to live migrate the container to a much more powerful server. Once the migration is complete, the container should continue rendering from 30%.
  • LXD allows you to limit resources used by each container. Remember the example with one LXC container for each user that needs to test commands in a Linux environment? Well, LXC containers are not virtual machines. So they don't have fixed reserved memory, like virtual machines do. Each container can access all the memory on a server. If one container uses up all the memory, there is nothing left for the other users. So it can ruin everyone's experience. LXD allows you to establish that each container can only use 512MB of memory, or something like that. Or you can limit how much CPU time each container can use.

There are many more features like this. The thing is, there is rarely a reason to not use LXD. So if you have that option, just install LXD directly. The LXC dependencies will be pulled in automatically.

Hopefully, this clears up when you should use Docker containers and when you should use LXC containers. Maybe you even get some cool ideas about how to creatively use LXC to build an interesting online service.
