Kubernetes

What Is Kubernetes DaemonSet and How to Use It?

In Kubernetes, a Deployment is a higher-level abstraction built on top of ReplicaSets. In other words, a Deployment provides a simpler, higher-level interface for managing and scaling applications, while ReplicaSets are the lower-level building blocks that a Deployment uses to achieve this.

When you create a Deployment, you specify the number of replicas(copies) you want to run, the container image to use, and various other details about your Pods. Kubernetes then creates a ReplicaSet and schedules the specified number of replicas of your Pod on the nodes in your cluster.

The ReplicaSet created by the Deployment is responsible for ensuring that the specified number of replicas are running at all times. It is possible that some nodes in the cluster may not have any replicas of the Pod running on them. This is because the ReplicaSet will only ensure that the specified number of replicas are running across the entire cluster, regardless of which nodes they are running on.

However, there may be cases where you want to ensure that a specific Pod runs on all nodes in the cluster. For example, if you want to run a logging agent on all nodes to collect log data or run a node-level service like a network plugin or storage daemon. In such scenarios, you can use Kubernetes DaemonSets.

What is a Kubernetes DaemonSet?

A DaemonSet is a Kubernetes resource that ensures a specified Pod runs on all nodes or a specific subset of nodes in a cluster. DaemonSets are commonly used to deploy special programs that run in the background, performing tasks such as monitoring and logging.

For example, a log collector daemon gathering log data from all the other programs running on a node. A monitoring agent tracking of the node's performance and send alerts if there are any issues.

For instance, assume you have a Kubernetes cluster with three nodes: node 1, node 2, and node 3, and you want to collect logs from all three. You can use the DaemonSet to ensure a replica of a logging Pod runs on all three nodes.

If you then add a new node, node 4, to the cluster, the DaemonSet will automatically schedule a replica of the logging Pod to run on node 4. Similarly, if you remove node 3 from the cluster, the DaemonSet will automatically terminate the replica of the logging Pod running on node 3.

Why Use a DaemonSet?

Some common use cases of DaemonSets are as follows:

Logging and monitoring: DaemonSets are often used to ensure that a logging agent or a monitoring tool is running on every node in the cluster. This way, these agents or tools can collect data from each node and provide valuable insights into the health and performance of the cluster.
Cluster storage: DaemonSets can be used to manage and maintain storage on every node in a cluster. For example, you might use a DaemonSet to run a distributed storage system such as Ceph to ensure that your storage infrastructure is highly available, scalable, and performant.
Node resource monitoring: DaemonSets can also be used to monitor resource utilization on each node in a cluster. By running monitoring systems such as Prometheus, you can collect data on CPU usage, memory usage, disk usage, and other resource metrics. This data can then be used to optimize resource allocation and identify performance issues.

Now that we understand what a DaemonSet is and its most common use cases, let's dive deeper into how to use it in your Kubernetes cluster.

Prerequisites

To follow along with the examples in the coming sections, you will need:

A running Kubernetes cluster with at least two worker nodes.
The kubectl command-line tool is installed on your local computer. kubectl is a tool used to interact with Kubernetes clusters. It's required to deploy and manage resources on Kubernetes.

Note that all the commands and their outputs provided in the examples have been tested on a multi-node (1 master node and 2 worker nodes) Kubernetes cluster created using Minikube. If you have Minikube already installed, you can set up a multi-node cluster by following the instructions provided in this tutorial.

Creating a DaemonSet

A DaemonSets is created by submitting a DaemonSet YAML configuration file to the Kubernetes API server. The example below demonstrates how to create a fluentd logging agent on each node in a specific cluster.

We start by creating a file, "fluentd.yaml" describing the DaemonSet.

apiVersion: apps/v1
kind: DaemonSet
metadata:
 name: fluentd
spec:
 selector:
   matchLabels:
     app: fluentd
 template:
   metadata:
     labels:
       app: fluentd
   spec:
     containers:
     - name: fluentd
       image: fluent/fluentd
       volumeMounts:
       - name: varlog
         mountPath: /var/log
       - name: varlibdockercontainers
         mountPath: /var/lib/docker/containers
         readOnly: true
     terminationGracePeriodSeconds: 30
     volumes:
     - name: varlog
       hostPath:
         path: /var/log
     - name: varlibdockercontainers
       hostPath:
         path: /var/lib/docker/containers

A DaemonSet configuration file needs to have the following fields:

apiVersion: The "apiVersion" field refers to the version of the Kubernetes API you're using to create this object.
kind: The "kind" field specifies the type of object being created (a DaemonSet in this case).
metadata: The "metadata" field provides information about the object being created, including the name of the object.
spec: The "spec" field is where you provide the actual details of the DaemonSet, including the Pod template (.spec.template). The Pod template is a template of the Pod that the DaemonSet will be creating replicas of. In addition to the required fields for a normal Pod, a Pod template in a DaemonSet must also specify appropriate labels. These labels are used to identify the Pods for which the DaemonSet is responsible. You must also specify a Pod selector in the DaemonSet's ".spec.selector" field. This selector is used to match the labels of the Pod template so that the DaemonSet knows which Pods it should be managing.

Now that you know how to write a valid DaemonSet configuration, you can use the "kubectl apply" command to submit the DaemonSet to the Kubernetes API:

kubectl apply -f fluentd.yaml

After the "fluentd" DaemonSet has been successfully submitted to the Kubernetes API, you can use the "kubectl describe" command to check its current state:

kubectl describe daemonset fluentd

Note that the screenshot above is a shortened version of the complete output.

The output shows that a "fluentd" Pod was successfully deployed on all three nodes of our cluster. You can confirm this by using the "kubectl get pods" command with the "-o" flag to display the nodes that each "fluentd" Pod was assigned to.

kubectl get pods -l app=fluentd -o wide

Limiting DaemonSets to Specific Nodes

DaemonSets are most commonly used to run a Pod across every node in a Kubernetes cluster. However, there may be cases where you want to run a Pod on only a subset of nodes.

For example, if you have a workload that requires fast storage, you would want to deploy that workload only to the nodes that have fast storage available. In cases like these, you can use node labels to tag specific nodes that meet the requirements of the workload.

Add Labels to Nodes

You can add the desired set of labels to a subset of nodes using the kubectl label command. The following command adds the label ssd=true to the node daemonset-demo-m03:

kubectl label nodes daemonset-demo-m03 ssd="true"

Now you can filter the node that has the "ssd" label set to "true" using the kubectl get nodes command with the –selector flag.

kubectl get nodes --selector ssd="true"

Node Selectors

Node selectors are a way to control which nodes in a Kubernetes cluster a Pod can be scheduled on. This allows you to specify certain requirements for the node that the Pod will run on, such as specific hardware or storage resources.

Let's delete the DaemonSet created in the previous section and create one with node selectors.

kubectl delete daemonset fluentd

The previous "fluentd" DaemonSet is now deleted. Next, replace the contents of the "fluentd.yaml" file with the code snippet below:

apiVersion: apps/v1
kind: DaemonSet
metadata:
 name: fluentd
spec:
 selector:
   matchLabels:
     app: fluentd
 template:
   metadata:
     labels:
       app: fluentd
   spec:
     nodeSelector:
       ssd: "true"
     containers:
     - name: fluentd
       image: fluent/fluentd
       volumeMounts:
       - name: varlog
         mountPath: /var/log
       - name: varlibdockercontainers
         mountPath: /var/lib/docker/containers
         readOnly: true
     terminationGracePeriodSeconds: 30
     volumes:
     - name: varlog
       hostPath:
         path: /var/log
     - name: varlibdockercontainers
       hostPath:
         path: /var/lib/docker/containers

This DaemonSet is configured to only run on nodes with the label ssd="true" by defining the "nodeSelector" field in the Pod spec.

Run the following command to submit the DaemonSet to the Kubernetes API:

kubectl apply -f fluentd.yaml

Since there is only one node (daemonset-demo-m03) with ssd="true" label, the "fluentd" Pod will run only on that node:

kubectl get pods -l app=fluentd -o wide

Updating a DaemonSet

When you want to update a DaemonSet, you can use the RollingUpdate strategy, which allows you to incrementally update the Pod instances with new ones.

Replace the contents of your "fluentd.yaml" file with the following code snippet:

apiVersion: apps/v1
kind: DaemonSet
metadata:
 name: fluentd
spec:
 selector:
   matchLabels:
     app: fluentd
 updateStrategy:
   type: RollingUpdate
   rollingUpdate:
     maxUnavailable: 1
 template:
   metadata:
     labels:
       app: fluentd
   spec:
     containers:
     - name: fluentd
       image: fluent/fluentd:v1.2
       volumeMounts:
       - name: varlog
         mountPath: /var/log
       - name: varlibdockercontainers
         mountPath: /var/lib/docker/containers
         readOnly: true
     terminationGracePeriodSeconds: 30
     volumes:
     - name: varlog
       hostPath:
         path: /var/log
     - name: varlibdockercontainers
       hostPath:
         path: /var/lib/docker/containers

You can configure the update strategy using the "spec.updateStrategy.type" field. This field should be set to "RollingUpdate" to enable the rolling update. Any changes you make to the "spec.template" field (or subfields) of the DaemonSet will trigger a rolling update.

The "spec.updateStrategy.rollingUpdate.maxUnavailable" parameter tells Kubernetes how many Pods can be updated at the same time during the rolling update. For example, if you set it to "1", only one Pod will be updated at a time, and all other Pods will continue running normally.

To see the rolling update in action, run the following command:

kubectl apply -f fluentd.yaml

Once the rolling update has started, you can use the "kubectl rollout" commands to see the current status of the DaemonSet rollout. To see the current rollout status of the "fluentd" DaemonSet, run the following command:

kubectl rollout status ds/fluentd

Deleting a DaemonSet

You can delete a DaemonSet using the "kubectl delete" command. Note that deleting a DaemonSet will also delete all the Pods being managed by that DaemonSet.

kubectl delete -f fluentd.yaml

If you are looking to certify your Kubernetes skills, check out these courses from KodeKloud:

FAQ

Is DaemonSet a Deployment?

No, a DaemonSet is not a Deployment. Though both are Kubernetes objects used to manage the desired state in a Kubernetes cluster, they serve different purposes.

In a deployment, you specify the desired number of replicas (copies) of a Pod to be running on all nodes in the cluster. In contrast, a DaemonSet ensures that a Pod is running on all or a specific subset of nodes in the cluster.

It’s also important to note that Deployment objects are used to manage stateless applications (applications that do not maintain any persistent data or state). DaemonSets, on the other hand, are useful for running a particular background task or service on every (or some) node in the cluster, such as a logging agent or a monitoring tool.

If you're interested in learning more about Kubernetes objects, I highly recommend checking out the blog post, What Are Objects Used for in Kubernetes? 11 Types of Objects Explained?

Is the Kubernetes Kubelet a DaemonSet?

No, a Kubernetes kubelet is not a DaemonSet.

While it’s true that the kubelet runs on each worker node, it is not a higher-level Kubernetes object (like a DaemonSet is) used to deploy and manage Pods across a cluster. A kubelet is an agent responsible for running and managing the containers associated with a Pod, as specified by Kubernetes objects like Deployments or StatefulSets.

Embark on a Kubernetes mastery journey with our Kubernetes Learning Path:

Conclusion

Kubernetes DaemonSets allows you to run a copy of a Pod on all nodes or a subset of nodes in your cluster. This makes it easy to distribute system-level components like logging agents or monitoring agents.

By following the steps outlined in this post, you should now have a good understanding of what a DaemonSet is and how to use it in your own Kubernetes cluster.
